GP 680
The GP680 is essential for growing organisations because of its unique versatility. When necessary, the radio can easily be programmed in the field to add or delete features. So, whether it's the harsh environment of a construction site or the elegance of an exclusive hotel, the radio of choice is the Versatile. It's the radio that grows with you.

General Specifications
Channel Capacity : 16 (Conventional Mode)
Power Supply : Rechargeable battery 7.5v

Dimensions: H x W x D (mm) Height excluding knobs
With standard high capacity NiMH battery : 137 x 57.5 x 37.5
With ultra high capacity NiMH battery : 137 x 57.5 x 40.0
With NiCD battery : 137 x 57.5 x 40.0
With Lilon battery : 137 x 57.5 x 33.0

Weight: (gm)
With Standard high capacity NiMH battery : 428
With Ultra high capacity NiMH battery : 508
With NiCD battery : 458
With Lilon battery : 358

Average Battery Life @5/5/90 Cycle:

Low Power
High Power
With Standard high capacity NiMH battery
11 hours
8 hours
With Ultra high capacity NiMH battery
14 hours
11 hours
With NiCD battery 12 hours 9 hours
With Lilon battery 11 hours 8 hours

- Signalling: The fully compliant MPT signalling package includes MPT1343, Regionet 43 and ANN modes of operation. Radios are configurable for up to 4 personalities including Talkgroup Select and Conventional signalling.

- X-Pand™ Voice Compression and Low Level Expansion: Crisp, clear and strong audio quality in virtually any noisy environment. Low level expansion allows further improvements in audio quality by reducing noise usually heard during pauses in conversation.

- User Information: A 14-character alpha-numeric display contains a battery gauge and signal quality indicator and provides separate distinctive tones plus name decode for many incoming calls.

- Ease of Use: One touch dialling, simple menus and an alpha-numericphonebook/contact list make the full power of GP680 simple and intuitive to use.

- Dynamic Regrouping: Provides over-the-air reconfiguration of the radio plus download of group identity in a meaningful alpha-numeric form.

- Option Board Expandability: You can expand the capabilities of GP680 by adding option boards such as Voice Storage.

- Wideband and Programmable Channel Spacing: Provides flexibility in deployment and stocking.

Efficient, effective communication is key to sustaining success and simplifying your life as a professional. Motorola´s enhanced GP Series of Professional Radios is the answer. At the touch of a button, these radios offer instant contact among all your personnel, helping to keep them productive. Beyond that, your teams can be controlled from a distance, ensuring your organization is running at a high level of efficiency at all times.
Clearly, these radios offer the ability to make you and your entire organization more efficient. But, most importantly, the enhanced GP series of radios can help you keep your professional edge ... whatever your profession

Specifications

GP 320

GP 344 SMALL

GP 388 SMALL

GP 340/640

GP 360/380

GP 680/1280 TRUNK

Number of Channels

1

16

250

16

225

Trunk Kanallarý

Programmable Keys

2

4

4

4

4

27

X-PandTM

*

*

*

*

*

*

Optional Boards







*

*

*

Channel Scanning



*

*

*

*

*

Keypad & Alpha-numeric Display





1 satýr ekran



1 satýr ekran

4 satýr ekran

Battery





*



*

*

Rapid CallTM





*



*

*

Signalling











*

Voice Recording











*

Pager
